Loco Positioning system

Position awareness

Add absolute position to your Crazyflie 2.X using the Loco Positioning system.

The Crazyflie 2.X (as most other quadcopters and robots) has no real notion of its position in space. The on board sensors (accelerometers and gyros) can be used to give a rough idea of its movements but lacks the accuracy for long term position awareness. The solution is to use an external system that can provide information of the current position. Outside GPS can be used, but indoor the options are limited, often complex, expensive or both. That is why we have created the Loco Positioning system.

The system

The Loco Positioning system is a local positioning system that is used to find the absolute 3D position of objects in space. It is in many ways similar to a miniature GPS system. The base of the system is a set of Anchors that are positioned in the room (compare to the satellites in GPS), they are the reference. The other part of the system is one or more Tags (compare to the GPS receiver) that are fixed to the object(s) that are to be tracked. By sending short high frequency radio messages between the Anchors and Tags, the system measures the distance from each Anchor to the Tags and calculates the position of the Tags from that information. All information needed to calculate the position is available in the Tag which enables position estimation on board of the Crazyflie, as opposed to many other positioning systems where the position is calculated in an external computer and sent to the Crazyflie. By adding knowledge of its position to a Crazyflie 2.X it is capable of flying autonomously without manual control. This opens up an array of exciting use cases and applications.

The Loco Positioning Deck

The Loco Positioning Deck is a Crazyflie 2.X expansion deck with the Loco Positioning Tag functionality. Read more on the Loco Positioning Deck page.

The Loco Positioning Node

The Loco Positioning Node is a multi functional node in a Loco Positioning system, it can act either as an Anchor or Tag. As an Anchor it is part of the reference base for the system while running in Tag mode it can be attached to an object to track, for instance a robot. Read more on the Loco Positioning Node page.

Positioning modes

The Loco Positioning System implements three different positioning modes, Two Way Ranging (TWR), Time Difference of Arrival 2 (TDoA 2) and Time Difference of Arrival 3 (TDoA 3).

In TWR mode, the tag pings the anchors in sequence, this allows it to measure the distance between the tag and the anchors. Using this information, a theoretical minimum of 4 Anchors is required to calculate the 3D position of a Tag, but a more realistic number is 6 to add redundancy and accuracy.

This mode is the most accurate mode and also works when the tag or Crazyflie leaves the space delimited by the anchors. The tag is actively communicating with the anchors in a time slotted fashion and in this mode only one tag or Crazyflie can be positioned with a maximum of 8 anchors.

In TDoA 2 mode, the anchor system is continuously sending synchronization packets. A tag listening to these packets can calculate the relative distance to two anchors by measuring the time difference of arrival of the packets. From the TDoA information it is possible to calculate the 3D position in space. In this mode the tag is only passively listening, so new tags do not add any load to the system which makes it possible to position any number of tags or Crazyflies simultaneously. This makes it a perfect mode for swarming.

Compared to TWR, TDoA 2 is more restrictive when it comes to the space where positioning works, ideally the tag should always be within, or very close to, the space delimited by the anchor system. This means that TDoA 2 works best with 8 anchors placed in the corners of the flying space. In this space the accuracy and precision is comparable to TWR.

In this mode the anchor system is time slotted and synchronized and the number of anchors is limited to 8.

The TDoA 3 mode has many similarities with TDoA 2 and supports any number of tags or Crazyflies. The main difference is that the time slotted scheme of TDoA 2 has been replaced by a randomized transmission schedule which makes it possible to add more anchors. By adding more anchors the system can be scaled to larger spaces or span multiple rooms without line of sight between all anchors. It also makes it more robust and can handle loss or addition of anchors dynamically.

The estimated position in this mode is slightly more noisy compared to TDoA 2.


The Loco Positioning system is based on the Decawave DWM1000 chip and has an accuracy in the 10 cm range. The 3D positioning performance depends of the system setup and environment.

The Loco Positioning system has mainly been designed for indoor use.

Getting started with Loco positioning

We have created an easy to follow step-by-step guide for setting up the Loco positioning system that you will find here. In the tutorial we use the Indoor explorer bundle that you can buy directly from our E-shop. For more technical information about the Loco positioning system please visit our wiki.

Used by Lund University

At the Centre for Mathematical Sciences at Lund University PhD student Kenneth Bastone and professor Kalle Åström are currently using the Crazyflie and the Bitcraze ultra-wide band based Loco Positioning system as part of their research. We visited them and wrote a blog post about their work.

Centre for Mathematical Sciences

To read the blog post go here.

If you have any further questions please contact support@bitcraze.io
